IdroMOP H6
Developed to control and manage any pumping group
The IdroMOP H6 device is designed for the maximum flexibility and versatile management of pumping units. IdroMOP H6 offers the best automation in the irrigation industry with optimization of irrigation cycles.
Intuitive graphics and accurate and timely information enable work with total peace of mind and reliability. In automatic mode, the device operates autonomously at each irrigation stage: pump priming, motor startup and warm-up, system filling, motor speed and/or pressure adjustment, completion of the working cycle, motor slowdown and cooling, and motor shutdown.
Through sensors installed on the pump unit, the IdroMOP H6 device constantly monitors the health of the motor, pump, and system.
The operator can monitor the irrigation process locally from the panel or remotely through the My ID4 application. Flow control and consumption display minimize water and fuel wastage.
Functions
Automatic pump priming
Delivery valve management
System fill control
Periodic duty cycle management
Instantaneous flow control
Programmable irrigation duration up to 48 hours
Motor, system, and electrical protection
Manual motor speed setting
Automatic water pressure control
Operating hours counter
Maintenance notice
Managed applications
Motor pump
From the simple mechanical pump engine to the more modern STAGE V emission engine, with or without urea. One device for all engines.
Generator + Electric pump
Generator control and one or two electric pumps. Integrated inverter interface via RS-485 communication line associated with safety I/O lines. Soft-start control reduces starting torque by decreasing mechanical stress to the system.
Electric pump
For GREEN systems, our solution for exclusive use of electric pumps. For increasingly sustainable irrigation.
Advanced functions
STAGE V
The use of Stage V-emitted engines results in a significant reduction in emissions.
IdroMOP H6 devices adopt the best strategies in compliance with Stage V regulations. Supervision of particulate filter clogging, verification of additive quality and level, and engine oil contamination control are just some of the functions built into our IdroMOP H6 devices.
INVERTER
IdroMOP H6 enables the complete management of inverters to control electric motors, offering significant advantages in efficiency, energy savings, and precision in water resource management. These devices allow the speed of the motors to be adjusted with extreme precision, adapting the water flow to the specific needs of the crops. To complement this, it is possible to manage submersible pumps via soft start, further improving the efficiency of the ‘irrigation system.
PUMPING UNIT
Through the ID4 platform, up to 8 motor pumps, or electric pumps, can be connected and made to work as one.
Start, stop and working point of all pumps will always be synchronized, and in case of an abnormality the whole pumping unit will be stopped in a controlled way.
Advanced functions
STAGE V
INVERTER
PUMPING UNIT
The use of Stage V-emitted engines results in a significant reduction in emissions.
IdroMOP H6 devices adopt the best strategies in compliance with Stage V regulations. Supervision of particulate filter clogging, verification of additive quality and level, and engine oil contamination control are just some of the functions built into our IdroMOP H6 devices.
IdroMOP H6 enables the complete management of inverters to control electric motors, offering significant advantages in efficiency, energy savings, and precision in water resource management. These devices allow the speed of the motors to be adjusted with extreme precision, adapting the water flow to the specific needs of the crops. To complement this, it is possible to manage submersible pumps via soft start, further improving the efficiency of the ‘irrigation system.
Through the ID4 platform, up to 8 motor pumps, or electric pumps, can be connected and made to work as one.
Start, stop and working point of all pumps will always be synchronized, and in case of an abnormality the whole pumping unit will be stopped in a controlled way.
Functions
Automatic pump priming
Delivery valve management
System fill control
Periodic duty cycle management
Instantaneous flow control
Programmable irrigation duration up to 48 hours
Motor, system, and electrical protection
Manual motor speed setting
Automatic water pressure control
Operating hours counter
Maintenance notice
SIZE
WEIGHT
CASE
PROTECTION
POWER
ABSORPTION
192.5 x 198 x 62 mm
600g
ABS + Polycarbonate
IP65
8 – 30 Vdc
100 – 220 mA
Coverage
165 countries
Network
LTE Cat 1
Geolocation
GNSS
Frequencies
LTE-FDD:
B1,B2,B3,B4,B5,B7,B8,B12,B13,
B18,B19,B20,B25,B26,B28,B66.
LTE-TDD:
B34,B38,B39,B40,B41.
COVERAGE
NETWORK
GEOLOCATION
FREQUENCIES
165 countries
LTE Cat 1
GNSS
LTE-FDD:
B1,B2,B3,B4,B5,B7,B8,B12,B13,
B18,B19,B20,B25,B26,B28,B66.
LTE-TDD:
B34,B38,B39,B40,B41.
Dimensions
192.5 x 198 x 62 mm
Weight
600g
Case
ABS + Polycarbonate
Protection
IP65
Power supply
8 – 30 Vdc
Power consumption
100 – 220 mA
Models
IdroMOP H6
STD
- Complete engine management and protection
- Complete irrigation process management and plant protection
- Manual adjustment of engine speed
- Automatic pressure adjustment
-
Electronic motor management via CAN BUS
-
Inverter management via RS - 485
-
4G modem + integrated SIM card
-
GPS Geolocation
-
Remote control
IdroMOP H6
ID4
- Complete engine management and protection
- Complete irrigation process management and plant protection
- Manual adjustment of engine speed
- Automatic pressure adjustment
- Electronic motor management via CAN BUS
-
Inverter management via RS - 485
- 4G modem + integrated SIM card
- GPS Geolocation
- Simplified remote control with annual subscription
IdroMOP H6
ID4 Platinum
- Complete engine management and protection
- Complete irrigation process management and plant protection
- Manual adjustment of engine speed
- Automatic pressure adjustment
- Electronic motor management via CAN BUS
- Inverter management via RS - 485
- 4G modem + integrated SIM card
- GPS Geolocation
- Full remote control with 3, 6 or 12-month subscriptions
- Click above the bold headlines
Speed sensor
Vacuum sensor
Pulse Anemometer
Pressure transducer
Linear actuator
Shielded inductive proximity sensor for reading speed signal on sprinkler machines
Absolute sensor for detecting the water vacuum at the inlet of the pumping unit
Tool for determining wind speed
Sensor for sensing water pressure at the discharge of a pumping unit or as a pressure switch for an irrigation machine
The linear actuator can be used with bracketing on the diesel feed pump to control engine speed
4G high gain magnetic antenna
4G 2M magnetic antenna
4G + GPS 2M magnetic antenna
3M GPS / GLONASS magnetic antenna
High-gain antenna with magnetic base for receiving 5G / 4G / 3G / 2G signals
Antenna with magnetic base for receiving 4G/ 3G / 2G signals
Antenna with magnetic base for receiving 4G and GPS signals
Antenna with magnetic base for receiving GPS and GLONASS signals
CAN BUS
PRIMING
PUMPING GROUPS
IRRIGATION MACHINES
ADAPTERS
ACCESSORIES
CAN BUS extension cable Male-Female L 900mm / 1800mm / 2700mm
Splitter cable – Deutsch
CAN BUS extension cable Female-Female 7000mm
Splitter cable – Molex
Priming wiring for electric pump 30A / 70A
Universal structured motor harness 32V6
TIERIII IdroMOP motor harness 0010_V0
John Deere motor harness
Stage V 2M motor harness – Sicma 24 pos
FPT Stage V motor harness – FCI 14 pos
Adapter Elcos A/B JPT42 CEM-190/196
Adapter Mate-N-Lock JPT42 COD. 0047_00
Adapter Irtec Souriau 18-JPT42
Adapter Matermacc plant
Adapter CANBUS 40CM CONN. DT4/CPC4 COD.0069_1A
Speed sensor
Shielded inductive proximity sensor for reading speed signal on sprinkler machines
Vacuum sensor
Absolute sensor for detecting the water vacuum at the inlet of the pumping unit
Pulse Anemometer
Tool for determining wind speed
Pressure transducer
Sensor for sensing water pressure at the discharge of a pumping unit or as a pressure switch for an irrigation machine
Linear actuator
The linear actuator can be used with bracketing on the diesel feed pump to control engine speed
Magnetic antenna4G high gain
High-gain antenna with magnetic base for receiving 5G / 4G / 3G / 2G signals
Magnetic antenna 4G 2M
Antenna with magnetic base for receiving 4G/ 3G / 2G signals
Magnetic antenna 4G + GPS 2M
Antenna with magnetic base for receiving 4G and GPS signals
Magnetic antenna GPS/GLONASS 3M
Antenna with magnetic base for receiving GPS and GLONASS signals
CAN BUS
CAN BUS Plug Wiring JPT42 0074_00
CAN BUS extension cable Male-Female L 900mm / 1800mm / 2700mm
Splitter cable – Deutsch / Molex
CAN BUS extension cable Female-Female 7000mm
Extension cable Molex Deutsch 900mm
Priming
Compressor priming wiring
Priming harness for 30A / 70A electric pump
Pumping units
Frayed motor harness 31V5
Universal structured motor harness 32V6
FPT TIERIII IdroMOP motor harness 0010_V0
John Deere engine harness
Stage V 2M engine harness – SICMA 24 POS
FPT Stage V – FCI 14 POS engine harness
Irrigation Machines
Wiring IrriMOP hydraulic machine 0049_00
Wiring for IrriMOP turbine machine 0053_2A
Adapters
Elcos A/B JPT42 adapter COD. 0056_00
Mate-N-Lock JPT42 adapter COD. 0047_00
Irtec Souriau 18-JPT42 adapter
Matermacc implant adapter
CANBUS 40CM CONN. DT4/CPC4 adapter COD.0069_1A
Servo CPC16/DT4 adapter
Accessories
Metre-pack cable 150 MPF 5M/ 10M
Speed Sensor Extension M12-SS3 5M
Speed Sensor Cable QE12-N4G2-U 2M/5M
